Bulldog 24000 Pound 2-Speed Tandem Square Trailer Jack Set with Spring Return Drop Leg and Cross Shaft Crank Handle 500150

$999.99

2-SPEED SQUARE JACKS The First 2-Speed Gearbox Designed with a Drop Leg Jack in Mind.

BULLDOG’s 2-speed 12,000 lbs. support capacity square jack makes cranking easier when fully loaded and faster when unloaded. In low gear, the ratio delivers full lifting power at a super-smooth, easy-lifting traditional gearbox 29 turns per 1" of travel. In high gear, the  cranking ratio is a speedy 9 turns per 1" of travel, the fastest in its weight class. Adding another 12,000 lbs. companion Jack and connecting the two with a crosshaft give you a rating of 24,000 lbs. support and 20,000 lbs. of lifting capacity. Also included is a special handle intended specifically for 2-Speed Jacks. Non-slotted design for better weather resistance and 2-speed performance. Remains firmly attached for convenience or may be removed easily for theft deterrence. The plunger pin for the drop leg will be facing you on curbside or roadside.

When determining whether this landing gear can lift your load, please keep in mind that you’re only lifting the tongue weight and not the whole trailer in the air.

What's Included:
Bulldog  2-Speed 12,000 lbs Square Trailer Jack Drop Leg w/ Spring Return Traditional Gearbox 26" Lift
Bulldog 12,000 lb Trailer Jack
Crank Handle for 2-Speed Jacks
Cross Shaft Tube (Can be cut)


• State of the art 2 speed gearbox with power and speed for the most effective and efficient jack at all loads

• Designed for today’s standard agricultural,  construction and industrial trailer applications.

• User friendly design makes operation smooth  and easy

• Drop Leg increases overall extension

• Engineered alloys for enhanced strength, stability and sideload capability

• Painted outer tube, inner tube, and drop leg.



Specifications:

• Support Capacity: 12,000 lbs. per Jack, 24,000 lbs as a system

• Lift Capacity: 10,000 lbs. per Jack, 20,000 lbs as a system

• Retracted Height: 28.5"

• Extended Height: 54.6"

• Travel/Lift: 12.5"

• Spring Return Drop Leg allows 13.5” of additional adjustment

• Standard disc foot included

• Drop Leg Pull Pin is on the side

• Crank Sold Separately

• 4" Tubing width

This Jack can be paired with the Bulldog 2-Speed Electric Powered Drive Motor Kit, please use part number 1824180100. This is a 2-Speed Motor Kit.

Recommended applications: PJ Downeaster Sundowner eby merhow Featherlite CM Kaufman Saratoga Classic Jamco 4 Star Sidekick Hawk Trail-et Sundowner Bri-Mar Big Tex Trails West Forest River Lexington dump construction equipment stock grain cart cherokee Trailerman cORN PRO McLander GatorMade Trailerman Cronkite Elite Boss Stillwater Brooks Bothers Horton
