Lippert 6-Pack (3-Pair) 12.25" x 3.38" Self-Adjusting Electric Trailer Brake Assemblies � Triple Axle (10K), Replaces Dexter, Al-Ko, Rockwell & Quality Axles
$724.99
Lippert 6-Pack (3-Pair) 12.25" x 3.38" Self-Adjusting Electric Trailer Brake Assemblies
This complete 6-pack (3-pair) of Lippert self-adjusting electric trailer brake assemblies is an ideal solution for triple axle setups rated at 10,000 lbs. Replace worn or damaged brakes with genuine Lippert assemblies that eliminate manual adjustments and deliver consistent stopping power. Designed to fit axles rated up to 10K, these assemblies are perfect replacements for Dexter, Al-Ko, Rockwell, and Quality Axles.
Bundle Contents:
-
QTY (3): Lippert Electric Trailer Brake Assembly - 12.25" x 3.38" 10,000 lbs. Left Side
- Replacement standard electric brake assembly with park
- Self-adjusting configuration eliminates the need for manual adjustments
- Designed for left-hand (roadside) installation only
- For axles rated to 10,000 lbs.
- Seven-bolt mounting pattern
- Easy, DIY installation (hardware sold separately)
- Fits 16", 16.5", 17" or 17.5" wheels
- Brake size: 12" x 3.38"
- New electric drum brakes require a break-in period to achieve full performance
- Dexter Compatible Part Number: K23-450-00|023-450-00
-
QTY (3): Lippert Electric Trailer Brake Assembly - 12.25" x 3.38" 10,000 lbs. Right Side
- Replacement standard electric brake assembly with park
- Self-adjusting configuration eliminates the need for manual adjustments
- Designed for right-hand (curbside) installation only
- For axles rated to 10,000 lbs.
- Seven-bolt mounting pattern
- Easy, DIY installation (hardware sold separately)
- Fits 16", 16.5", 17" or 17.5" wheels
- Brake size: 12" x 3.38"
- New electric drum brakes require a break-in period to achieve full performance
- Dexter Compatible Part Number: K23-451-00|023-451-00
We recommend verifying these brake assemblies match your trailer’s original equipment and performing regular brake inspections to ensure optimal safety and performance.
| Specifications: | |
|---|---|
| Kit Type | Complete Electric Brake Assembly Kit |
| Drum Brake Type | Self-Adjusting Brake Assembly |
| Drum Dimensions | 12-1/4" x 3-3/8" Drum |
| Drum Location | Left & Right |
| Axle Rating | 10,000 lbs |
| Mounting Pattern | 7-Bolt |
| Suitable Wheel Size | 16" - 17.5" |
Order today or call us at 877-869-6690 for expert advice and personalized service.
