Lippert Tandem Axle 12" x 2" Electric Brake & Pre-Greased 8 on 6.5" Hub Kit (5,200–7,000 lbs) – Dexter, Al-Ko, Rockwell Compatible
$779.99
Lippert Tandem Axle 12" x 2" Electric Brake & 8 on 6.5" Pre-Greased Hub Kit (5,200–7,000 lbs)
This bundle includes four complete kits, perfectly suited for tandem axle trailers. Each kit is compatible with Dexter, Al-Ko, and Rockwell systems, making it easy to upgrade or replace critical brake and hub components. With 12" x 2" electric brakes on both the left and right sides, plus pre-greased hubs featuring an 8 on 6.5" bolt pattern, your trailer will be ready for loads ranging from 5,200 to 7,000 lbs per axle.
Bundle Contents:
-
QTY (4): Complete Pre-Greased Hub Assembly with Lug Nuts - 7,000-lb. Axles, 1/2" Stud
- Each assembly includes:
- QTY (1): Pre-greased hub and drum assembly
- QTY (1): Dust cap with plug
- QTY (1): 1.75" cotter pin
- QTY (1): 1" 6-slot castle spindle nut
- QTY (1): Round spindle washer (1.06" ID, 2" OD)
- QTY (8): 60° cone trailer lug nuts
- 8 on 6.5" bolt pattern
- This bundle includes four (4) of these complete assemblies, ideal for tandem axle setups.
- Each assembly includes:
-
QTY (2): Lippert Electric Trailer Brake Assembly - 12" x 2" (Left Side)
- Replacement standard electric brake assembly with park
- Manual adjustment
- For axles rated 5,200–7,000 lbs (and 8,000-lb. hybrid axles)
- Five-bolt mounting pattern
- For 15" to 17.5" wheels
- Brake size: 12" x 2"
- Designed for left-hand (roadside) installation
- Requires a break-in period for optimal performance
- Dexter Compatible Part Number: K23-180-00|023-180-00
-
QTY (2): Lippert Electric Trailer Brake Assembly - 12" x 2" (Right Side)
- Replacement standard electric brake assembly with park
- Manual adjustment
- For axles rated 5,200–7,000 lbs (and 8,000-lb. hybrid axles)
- Five-bolt mounting pattern
- For 15" to 17.5" wheels
- Brake size: 12" x 2"
- Designed for right-hand (curb-side) installation
- Requires a break-in period for optimal performance
- Dexter Compatible Part Number: K23-181-00|023-181-00
For best results, confirm compatibility with your trailer’s original equipment, follow recommended maintenance intervals, and inspect all components regularly. Proper fit and upkeep help ensure a safer, smoother towing experience.
| Specifications: | Â |
|---|---|
| Kit Type | Complete Tandem Axle Brake & Hub Setup (4 Kits Total) |
| Axle Rating | 5,200–7,000 lbs |
| Brake Size | 12" x 2" |
| Brake Mounting Pattern | 5-Bolt |
| Hub Bolt Pattern | 8 on 6.5" |
| Hub Type | Pre-Greased Hub/Drum Assembly |
| Wheel Size Compatibility | 15"–17.5" (brakes), 16" recommended (hub) |
| Side Orientation | Left Side (2), Right Side (2) |
| Adjustment | Manual Adjust |
Order today or call us at 877-869-6690 for expert advice and personalized service.
